Key Feature
High module efficiency
Plus power tolerance:0~+ 3%.
Independently developed
anti-reflective and self-cleaning
Certified by TUV to withstand high level of wind loads (2400Pa) and snow loads (5400Pa)*.
Excellent performance under low light environments
Best Quality
• Junction box and bypass diodes guarantee the modules free of overheating and “hot spot effect”.
• Compatible with industry standard inverters and Mounting systems.
Guarantee minimal maintenace effort required.
• Potential Induced Degradation (PID) free.
| Performance at Standard Test Condition | |
| Maximum Power at STC(Pmax) | 500W |
| Short Circuit Current(Isc) | 9.8A |
| Open Circuit Voltage(Voc) | 71.9V |
| Maximum Power Current(Impp) | 9.5A |
| Maximum Power Voltage(Vmpp) | 58.9V |
| Module Efficiency | 17.78% |
| Power Tolerance | 0/+3% |
| Temperature Characteristics | |
| Nominal Operating Cell Temperature (NOCT) | 44 ±3°C |
| Temperature Coefficient of Pmax (γ) | - 0.42%/k |
| Temperature Coefficient of Voc (β) | 0.38%/k |
| Temperature Coefficient of Isc (α) | 0.06%/k |
| System Integration Parameters | |
| Maximum System Voltage | DC 1500V |
| Maximum Series Fuse | 15A |
| Maximum Reverse Current | 21.5A |
| Increased Snowload Acc. to IEC 61215 | 5400Pa |
| Operating Temperature | 40~+85°C |
| Number of Bypass Diodes | 3 |
| Product Warranty | |
| Modules per Box: | 36 pieces |
| Modules per 40’ Container: | 936 pieces |
| Warranty | |
| 15 year Product Workmanship Warranty | |
| 25 year Power Warranty | |
| 2% first year degradation | |
| 0.55% Annual Power Attenuation | |
| Mechanical Specification | |
| Cell Type | PolyCrystalline 157×157 mm |
| Number of Cells | 112 (8×14) |
| Dimensions (A×B×C) | 2279×1303×35mm |
| Weights | 31kg |
| Front Glass | 3.2 mm Low iron tempered glass |
| Frame | Anodized aluminum alloy |
| Junction Box | IP 67,with bypass diodes |
| Connector | MC4 compatible |
| Output Cables | TÜV standard, length 350mm, 4.0mm² |
